Procedure - Template

  1. Piano Composerにログインする
  2. [管理]タブメニューのテンプレートから「テンプレートを追加」をクリックする
  3. テンプレート名を任意に入力し、ユースケースを「ニュースレター」に設定し「ライブラリへ追加」をクリックする
  4. 作成したテンプレートを開き、「コンテンツフィールド」をクリックする
  5. コンテンツフィールドの入力項目設定を以下の Render Template Settings の通りに作成し、到達URLや画像URLなどの値はカスタマイズする
  6. 設問を複数用意する場合は、コンテンツフィールド編集の際に、設問用フィールドを設問数分増やす。
  7. 同様に「コードを編集」をクリックし、Render Template HTML と Render Template CSS のコードをコピーしてペーストする(CSS/HTML上での位置調整用の修正等は適宜行ってください)
  8. コードを編集する際に、複数設問がある場合は、HTMLコード中の”scope.questions”変数の要素を設問数分増やす。
  9. 「保存」をクリックする

Procedure - Experience

  1. Piano Composerにログインする
  2. 新規サイトエクスペリエンス、もしくは既存のエクスペリエンスの編集画面に入る
  3. 任意の対象ページ、ターゲットオーディエンス、イベント／トリガーを定義する
  4. アクションで「JSを実行」を選択し、以下の Experience Settings (RunJS) をコピーしてペーストする
  5. 同様にアクションで「JSを実行」を選択し、以下のCallback用JavaScript Experience Settings (RunJS/Callback) をコピーしてペーストする
  6. アクションの「テンプレートを表示」をドラッグし、上記で作成したRun JSの下にドロップする
  7. 表示設定を以下のように設定する。
    • タイプ：ページ上のインライン
    • コンテナのセレクター：#piano_inline
  8. 「保存」をクリックする

Render Template Settings (コンテンツフィールド)

Screenshot of ポップアップ
コンテンツフィールド名内容設定例
headerアンケートタイトル編集部からのアンケートに<br>ご協力お願いします
subheaderアンケートタイトル下プライバシーポリシーを確認する
subheader-linkプライバシーポリシー等へのリンクhttps://piano.io/
header-imageウィジェット左上の画像/企業ロゴ等をURL指定-
cta-text送信ボタンのテキスト回答を送信する
header-text-colorheaderのテキスト配色#323232
subheader-text-colorsubheaderのテキスト配色rgba(50, 50, 50, 0.7)
input-box-text-colorinput
cta-text-color送信ボタンのテキスト配色#ffffff
background-colorウィジェットの背景色#ffffff
question_id1設問のID。パフォーマンスパラメータのグループ名になります。(数字は複数設問の場合、適宜増やしてください)householdincome
question_text1設問の内容。パフォーマンスパラメータの値になります。(数字は複数設問の場合、適宜増やしてください)Q1: 世帯年収
question_type1設問の入力方法を指定してください。(数字は複数設問の場合、適宜増やしてください。またDMPイベント送信の仕様により複数選択には対応できませんのでご了承ください)text/radio/select
answer_choices1設問が選択式の場合の選択肢一覧です。カンマ区切りで指定してください。(数字は複数設問の場合、適宜増やしてください)〜300万円未満,300万円〜500万円未満,500万円〜700万円未満,700万円以上
footer_note設問下のテキスト。回答結果は記事執筆の参考にさせて頂きます。

Render Template HTML

<config close-button-type="boilerplate"></config>


<div class="pn-boilerplate pn-boilerplate--newsletter">
    <div hide-if-blank class="pn-boilerplate__header">
        <button ng-if="isShowBoilerplateCloseButton()" class="pn-boilerplate__close unbutton" type="button" ng-click="close()" external-event="offer-close-modal">
            <span class="visually-hidden"><t>Close</t></span>
      <span class="up"></span>
      <span class="down"></span>
          <!--<svg class="pn-boilerplate__close-icon" width="12" height="12" viewBox="0 0 12 12" fill="none" xmlns="http://www.w3.org/2000/svg">
              <path fill-rule="evenodd" clip-rule="evenodd" d="M4.586 6L.293 1.707 1.707.293 6 4.586 10.293.293l1.414 1.414L7.414 6l4.293 4.293-1.414 1.414L6 7.414l-4.293 4.293-1.414-1.414L4.586 6z" fill="#0F0F15"/>
          </svg>-->
        </button>
    </div>


    <signup-screen class="pn-boilerplate__body pn-boilerplate__body--initial-screen">
      <img class="header-image" src="[%% header-image %%]"/>
      <b class="pn-boilerplate__accent"><t>[%% header %%]</t></b>
      <p class="pn-boilerplate__text pn-boilerplate__text--subheader"><a href="[%% subheader_link %%]" target="_blank"><t>[%% subheader %%]</t></a></p>
      <form class="pn-boilerplate__form" id="pn-survey" action="post">
        <div class="pn-boilerplate__input-group" newsletter-signup-invalid="pn-boilerplate__input-group--error">
          <ng-container ng-repeat="q in questions">
            <div class="pn-survey-group">
              <div class="pn-survey-question">
                <label>{{q.question}}</label>
              </div>
              <div class="pn-survey-answer" ng-switch="q.type">
                <ng-container ng-switch-when="text">
                  <input ng-model="result[q.id]" type="{{q.type}}" value="">
                </ng-container>
                <ng-container ng-switch-when="radio">
                  <label name="{{q.id}}" ng-repeat="answer in q.answers" class="pianoj-survey-radio">
                    <input ng-model="result[q.id]" type="{{q.type}}" value="{{answer}}">{{answer}}
                  </label>
                </ng-container>
                <ng-container ng-switch-when="select">
                  <select name="{{q.id}}" ng-model="result[q.id]" class="pianoj-survey-select">
                    <option ng-repeat="answer in q.answers" value="{{answer}}">{{answer}}</option>
                  </select>
                </ng-container>
              </div>
            </div>
          </ng-container>
        </div>
        <button class="pn-boilerplate__button unbutton"
                id="pn-submit"
                type="submit"
                external-event="survey"
                external-event-result="{{result}}"
                ng-click="close()"><t>[%% cta-text %%]</t></button>
      </form>
      <p class="pn-boilerplate__text pn-boilerplate__text--footer"><t>[%% footer_note %%]</t></p>
    </signup-screen>


  <div custom-script>
  (function() {
    var scope = angular.element("#pn-survey").scope();
    console.log(scope);
    scope.questions = [
      {id: "[%% question_id %%]", type: "[%% question_type %%]", question: "[%% question_text %%]", answers: "[%% answer_choices %%]".split(",")}
    ];
    scope.result = {};
  }());
  function log() {
    console.log(angular.element("#pn-survey").scope());
  }
  </div>


</div>

Render Template CSS

/* scaffolding */


.visually-hidden {
    position: absolute;
    width: 1px;
    height: 1px;
    margin: -1px;
    border: 0;
    padding: 0;
    white-space: nowrap;
    -webkit-clip-path: inset(100%);
    clip-path: inset(100%);
    clip: rect(0 0 0 0);
    overflow: hidden;
}


.unbutton {
    margin: 0;
    padding: 0;
    color: inherit;
    text-decoration: none;
    background-color: rgba(0, 0, 0, 0);
    -webkit-box-shadow: none;
    box-shadow: none;
    text-shadow: none;
    outline: 0;
    border: 0;
}


p {
    margin: 0;
}


img,
svg {
    display: block;
    max-width: 100%;
    height: auto;
}
.header-image {
    width: 120px;
}


svg {
    margin: 0 auto;
}


b {
    display: block;
    font-weight: normal;
}


a,
button {
    -webkit-tap-highlight-color: rgba(0, 0, 0, 0);
}


* {
    -webkit-box-sizing: border-box;
    box-sizing: border-box;
}


/* general style */


.pn-boilerplate {
    width: 100%;
    font-family: "Roboto", "Helvetica", sans-serif;
    font-weight: 500;
    font-size: 14px;
    line-height: 24px;
    letter-spacing: 0.01em;
    color: rgba(50, 50, 50, 0.8);
    -webkit-font-smoothing: antialiased;
    text-align: center;
    background-color: [%% background-color %%];
    border: 1px solid rgba(50, 50, 50, 0.08);
}


.pn-boilerplate__header {
    position: relative;
    -webkit-box-sizing: border-box;
    box-sizing: border-box;
    display: -webkit-box;
    display: -ms-flexbox;
    display: flex;
    -webkit-box-orient: horizontal;
    -webkit-box-direction: normal;
    -ms-flex-direction: row;
    flex-direction: row;
    -webkit-box-align: center;
    -ms-flex-align: center;
    align-items: center;
    -webkit-box-pack: start;
    -ms-flex-pack: start;
    justify-content: flex-start;
    height: 64px;
    border-bottom: 1px solid rgba(50, 50, 50, 0.08);
    z-index: 100;
}


.pn-boilerplate__close {
    width: 45px;
    height: 100%;
    margin-left: auto;
    border-left: 1px solid rgba(50, 50, 50, 0.08);
    cursor: pointer;
}


.pn-boilerplate__close-icon {
    display: inline-block;
    vertical-align: middle;
    fill-opacity: 0.3;
    -webkit-transition: fill-opacity 0.1s linear;
    transition: fill-opacity 0.1s linear;
}


.pn-boilerplate__close:hover .pn-boilerplate__close-icon,
.pn-boilerplate__close:focus .pn-boilerplate__close-icon {
    fill-opacity: 1;
}


.pn-boilerplate__body {
    display: block;
    padding: 62px 72px 56px;
}


.pn-boilerplate__body--initial-screen {
    padding: 47px 24px 24px;
}


.pn-boilerplate__body--success-screen {
    padding: 44px 24px 42px;
}


.pn-boilerplate__pic {
    display: inline-block;
    vertical-align: top;
    margin-bottom: 36px;
}


.pn-boilerplate__accent {
    margin-bottom: 8px;
    font-size: 18px;
    line-height: 28px;
    font-weight: 400;
    color: [%% header-text-color %%];
}


.pn-boilerplate--newsletter .pn-boilerplate__accent {
    margin-bottom: 6px;
}


.pn-boilerplate__text {
    font-size: 14px;
    line-height: 24px;
    color: [%% subheader-text-color %%];
}


.pn-boilerplate--newsletter .pn-boilerplate__text--subheader {
    #max-width: 300px;
    margin: auto;
    font-weight: 400;
}


.pn-boilerplate__form {
    #display: -webkit-box;
    #display: -ms-flexbox;
    #display: flex;
    -webkit-box-pack: justify;
    -ms-flex-pack: justify;
    justify-content: space-between;
    max-width: 516px;
    margin: 20px auto 20px;
}


.pn-boilerplate__input-group {
    position: relative;
    -ms-flex-preferred-size: auto;
    flex-basis: auto;
    width: 100%;
    -webkit-box-flex: 1;
    -ms-flex-positive: 1;
    #flex-grow: 1;
    margin-right: 24px;
    text-align: left;
}


.pn-boilerplate__input-group::after {
    #content: "";
    #position: absolute;
    #top: 0;
    #left: 0;
    #display: block;
    #width: 48px;
    #height: 100%;
    #background-repeat: no-repeat;
    #background-position: 17px center;
    #background-size: 14px 10px;
    #pointer-events: none;
}


input.pn-boilerplate__input {
    width: 100%;
    height: 48px;
    padding: 6px 12px;
    font-family: inherit;
    font-size: 14px;
    line-height: 24px;
    color: [%% input-box-text-color %%];
    border: 1px solid rgba(54, 54, 54, 0.1);
    border-radius: 0;
    text-overflow: ellipsis;
    -webkit-appearance: none;
}


.pn-boilerplate__input:hover,
.pn-boilerplate__input:focus {
    outline: 0;
    -webkit-box-shadow: none;
    box-shadow: none;
}


.pn-boilerplate__input-group--error .pn-boilerplate__input {
    padding-right: 48px;
    border-color: #f23d3d;
}


.pn-boilerplate__input::-webkit-input-placeholder {
    font-family: inherit;
    color: rgba(54, 54, 54, 0.4);
}


.pn-boilerplate__input::-moz-placeholder {
    font-family: inherit;
    color: rgba(54, 54, 54, 0.4);
}


.pn-boilerplate__input:-ms-input-placeholder {
    font-family: inherit;
    color: rgba(54, 54, 54, 0.4);
}


input.pn-boilerplate__input--email {
    padding-left: 48px;
    /*background-repeat: no-repeat;*/
    /*background-position: 17px center;*/
    /*background-size: 14px 10px;*/
}


.pn-boilerplate__error-indicator {
    position: absolute;
    top: 0;
    right: 16px;
    display: none;
    bottom: 0;
    width: 16px;
    height: 16px;
    margin: auto;
    background-repeat: no-repeat;
    background-position: center;
    background-size: contain;
}


.pn-boilerplate__input-group--error .pn-boilerplate__error-indicator {
    display: block;
}


.pn-boilerplate__error-message {
    position: absolute;
    bottom: calc(100% + 10px);
    right: -10px;
    display: none;
    min-width: 240px;
    padding: 12px;
    font-size: 12px;
    line-height: 18px;
    letter-spacing: 0.01em;
    color: #ffffff;
    text-align: center;
    background-color: #ed2939;
    -webkit-box-shadow: 0 15px 40px rgba(54, 54, 54, 0.2);
    box-shadow: 0 15px 40px rgba(54, 54, 54, 0.2);
}


.pn-boilerplate__error-message::after {
    content: "";
    position: absolute;
    bottom: -4px;
    right: 14px;
    width: 8px;
    height: 8px;
    background-color: inherit;
    -webkit-transform: rotate(45deg);
    -ms-transform: rotate(45deg);
    transform: rotate(45deg);
}


.pn-boilerplate__error-indicator:hover .pn-boilerplate__error-message {
    display: block;
}


.pn-boilerplate__button {
    min-width: 204px;
    padding: 13px 18px 11px;
    font-family: "Roboto", "Helvetica", sans-serif;
    font-size: 11px;
    line-height: 24px;
    font-weight: 500;
    letter-spacing: 0.14em;
    color: [%% cta-text-color %%];
    text-transform: uppercase;
    background-color: [%% button-color %%];
    cursor: pointer;
}


.pn-boilerplate--newsletter .pn-boilerplate__button {
    min-width: 144px;
}


.pn-boilerplate__button::after {
    content: "";
    display: inline-block;
    width: 0;
    height: 9px;
    margin-left: 0;
    background-repeat: no-repeat;
    background-position: center;
    background-size: contain;
    -webkit-transition: all 0.2s linear;
    transition: all 0.2s linear;
    -webkit-transform: translateX(-30px);
    -ms-transform: translateX(-30px);
    transform: translateX(-30px);
}


.pn-boilerplate__button:hover::after,
.pn-boilerplate__button:focus::after {
    width: 12px;
    margin-left: 13px;
    -webkit-transform: translateX(0);
    -ms-transform: translateX(0);
    transform: translateX(0);
}


.pn-boilerplate--subscription .pn-boilerplate__button {
    margin: 45px 0 31px;
}


@media (max-width: 564px) {
    .pn-boilerplate {
        width: 100%;
    }
}


@media (max-width: 480px) {
    .pn-boilerplate__body,
    .pn-boilerplate--subscription .pn-boilerplate__body {
        padding-left: 24px;
        padding-right: 24px;
    }


    .pn-boilerplate__form {
        -webkit-box-orient: vertical;
        -webkit-box-direction: normal;
        -ms-flex-direction: column;
        flex-direction: column;
    }


    .pn-boilerplate__input-group {
        width: 100%;
        margin-right: 0;
        margin-bottom: 24px;
    }


    .pn-boilerplate__button {
        width: 100%;
    }
}


.pn-boilerplate__account {
    margin-left: auto;
}


.pn-survey-answer {
  margin-top: 10px;
}
.pn-survey-submit {
  margin-top: 10px;
  text-align: center;
}
.pn-description {
  font-size: smaller;
}


.pn-boilerplate__close{
  border-top:0;
    border-left: 0px;
    position: absolute;
    top: 15px;
    right: 15px;
    opacity: 0.4;
  height:100%;
}
.pn-boilerplate__close-icon path{
  fill:#333;
}
.pn-boilerplate__header{
  height:0px;
}
.pn-boilerplate__close-icon{
  opacity:1;
  fill-opacity:1;
}
.pn-boilerplate__body--initial-screen{
  padding:15px;
  box-shadow: 1px 4px 4px 5px rgb(0 0 0 / 15%);
}
.pn-survey-grou{
  color:#333;
}
.header-image{
  width: 55px;
    height: 28px;
    margin-bottom: 20px;
}
.pn-boilerplate__accent .ng-scope{
    font-size: 18px;
    font-weight: bold;
}
.pn-boilerplate--newsletter .pn-boilerplate__text--subheader .ng-scope{
    font-size: 14px;
}
.pn-survey-question .ng-binding{
    border-bottom: 1px solid #333;
    line-height: 1.4;
    padding-bottom: 5px;
}
label.pianoj-survey-radio{
    user-select: none;
    padding: 10px 0;
    border-bottom: 1px solid #ccc;
    display:-webkit-box;
    display:-webkit-flex;
    display:-ms-flexbox;
    display:flex;
    -webkit-box-align:center;
    -webkit-align-items:center;
    -ms-flex-align:center;
    align-items:center;
}
input.ng-valid{
    margin-right: 8px;
}
.pn-boilerplate__button{
    background-color: #035785;
    cursor: pointer;
    box-shadow: 0px 6px 0px 0 #033856;
    padding:11px
}
.pn-boilerplate__text .ng-scope{
    font-size: 12px;
}
.pn-boilerplate__input-group{
  margin-bottom:10px;
  margin-top:0px;
}
.pn-boilerplate__form form{
  margin-bottom:15px;
}
.pn-boilerplate__close{
  right:0
}
.pn-boilerplate__button{
  font-size:14px
}
.no-js body{
  background: rgba(0, 0, 255, 0);
}
  .pn-boilerplate__body--initial-screen{
  background: #ffffff;
  }
  .pn-boilerplate{
    width: 90%;
    margin: auto;
  }
.pn-boilerplate{
    border: 2px solid #e6e6e6;
}
.pn-survey-answer{
      margin-top: 3px;
}
.tp-iframe-wrapper{
  margin-top:20px;
  margin-bottom:-50px;
}
button.pn-boilerplate__close span{
  position: absolute;
  left: 5px;
  width: 36px;
  height: 2px;
  border-radius: 3px;
}
.up{
transform: rotate(45deg);
    top: 13px;
    background-color: #676767;
    z-index: 1000;
}
.down{
  transform: rotate(-45deg);
    top: 13px;
    background-color: #676767;
    z-index: 1000;
}

Experience Settings

  • このサンプルでは、クッキーで1日に1回の表示制御を行っています。
Screenshot of ポップアップ

Experience Settings (RunJS) -ウィジェット差し込み用要素の追加とテンプレートの表示-

(function(){
  var elid = "piano_survey";
  var el = document.getElementById(elid) || document.createElement('div');
  el.id = elid;
  el.style.position = "fixed";
  el.style.bottom = "20px"; //下から20px
  el.style.right = "5px"; //右から20px
  el.style.transform = "translateY(100%)"; //初期位置
  el.style.opacity = "0"; //初期透過
  el.style.transition = "all 1.5s";
  el.style["z-index"] = "9999";
  el.style.width = "385px";
  if(!document.getElementById(elid)) {
    document.body.insertAdjacentElement("beforeend", el);
  }
  var piano_inline = document.createElement('div');
  piano_inline.id = "piano_inline";
  el.appendChild(piano_inline);
  tp = window.tp || [];
  tp.push(["addHandler", "showTemplate", function(template) {
    if(template.containerSelector = "#" + elid) {
      setTimeout(function() {
        el.style.transform = "translate3d(0,0,0)";
        el.style.opacity = "1";
      }, 1500);
    }
  }]);
  tp.template.show({templateId:'/*テンプレートIDは作成したものをセットしてください*/', displayMode:'inline', containerSelector:'#piano_inline', trackingId: context.trackingId});
})();

Experience Settings (RunJS/Callback)

function sendSurveyEvent(event) {
  try {
    if(typeof event.params.result != 'undefined') {
      var result = JSON.parse(event.params.result);
      var customerPrefix = '/* お客様ごとに用意されているプレフィックスを指定してください */';
      var persistedQueryId = '/* /dmp/push API用のpersistedQueryIdをご用意ください */';
      if(result) {
        cX.setEventAttributes({origin: customerPrefix + "-web", persistedQueryId: persistedQueryId});
        cX.sendEvent("survey", result);
      }
    }
  }
  catch (e) { console.log(e); }
}
function setCookie(cname, cvalue, exdays) {
  var d = new Date();
  d.setTime(d.getTime() + (exdays*24*60*60*1000));
  var expires = "expires="+ d.toUTCString();
  document.cookie = cname + "=" + cvalue + ";" + expires + ";path=/";
}
function onCheckoutExternalEvent(event) {
  console.log(event.eventName);
  switch (event.eventName) {
    case 'survey':
      sendSurveyEvent(event);
      // don't break here
    case 'offer-close-modal':
      setCookie("_pc_survey_closed", "true", 14);
      break;
  }
  var elid = "piano_survey";
  var el = document.getElementById(elid) || document.createElement('div');
  el.style.display = "none";
}
tp.push(["addHandler", "checkoutCustomEvent", onCheckoutExternalEvent]);

Experience Settings(Cookie)

Screenshot of ポップアップ
